Mobx 学习进阶
[TOC]
项目代码
https://github.com/dL-hx/react-redux-guide
v1.0 …
v1.0 mobx练习v2.0 …
v2.0 todos案例Mobx官网: https://www.mobxjs.com/
简单可扩展的状态管理
- Mobx简介
背景,浏览器兼容性
- 开发前的准备
如何支持装饰器语法.
- Mobx+React
如何结合使用
- Mobx异步
异步更新本地状态
- Mobx数据监测
数据检测方法
- 综合案例
一 Mobx简介
1.1 Mobx介绍
状态管理库
推荐(Mobx5)-------- 支持ES6proxy浏览器, 不支持IE11,Node6
(Mobx4)-------- 支持ES5浏览器
让状态容易维护
2 准备工作
v1.0 …
v1.0 mobx项目搭建creact-react-app 创建项目
2.1 启用装饰器语法支持(方式1)
1. 弹射项目底层配置: npm run eject
2. 下载装饰器语法babel 插件: npm install @babel/plugin-proposal-decorators -D
3. 在package.json 文件中加入配置
"babel":{
"plugins": [
// ["import", {
// "libraryName": "antd",
// "libraryDirectory": "es",
// "style": "css" // `style: true` 会加载 less 文件
// }],
// ↓这里支持装饰器语法配置
["@babel/plugin-proposal-decorators", { "legacy": true }]
]
}相当于 => 在.babelrc文件加入配置
js
{
"presets": [ // 预设,用来加载代码配置
[
"@babel/preset-env",
{
"useBuiltIns": "usage",// 添加浏览器不支持的语法
"corejs": 3
}
]
],
"plugins": [// [导入的插件]
// ["import", {
// "libraryName": "antd",
// "libraryDirectory": "es",
// "style": "css" // `style: true` 会加载 less 文件
// }],
// ↓这里支持装饰器语法配置
["@babel/plugin-proposal-decorators", { "legacy": true }]
]
}2.2 启用装饰器语法支持(方式2)
shell
1. npm install react-app-rewired customize-cra @babel/plugin-proposal-decorators --save-dev
2. 在项目根目录下创建 `config-overrides.js` 并加入如下配置--save 和 --save-dev 的作用和区别:
https://blog.csdn.net/cvper/article/details/88728505
js
--save-dev => 等价于 -D 加入的工具,开发时候用
--save => 等价于 -S , 项目运行的必要文件config-overrides.js
js
const { override, addDecoratorsLegacy } = require("customize-cra");
const path = require("path");
module.exports = override(
addDecoratorsLegacy()
);完整配置less版本
shell
npm install antd
npm install react-app-rewired customize-cra babel-plugin-import
npm install less less-loaderjs
const { override, fixBabelImports, addLessLoader, addWebpackAlias, addDecoratorsLegacy } = require("customize-cra");
const path = require("path");
module.exports = override(
// 针对antd 实现按需打包：根据import来打包 (使用babel-plugin-import)
fixBabelImports("import", {
libraryName: "antd",
libraryDirectory: "es",
style: true, //自动打包相关的样式 默认为 style:'css'
}),
// 使用less-loader对源码重的less的变量进行重新制定，设置antd自定义主题
addLessLoader({
javascriptEnabled: true,
modifyVars: { "@primary-color": "#1DA57A" },
}),
//增加路径别名的处理
addWebpackAlias({
'@': path.resolve('./src')
}),
// 增加装饰器支持
addDecoratorsLegacy()
);最后修改启动配置package.json
js
"scripts": {
"start": "react-app-rewired start",
"build": "react-app-rewired build",
"test": "react--app-rewired test",
"eject": "react-scripts eject"
},最后运行 npm start , 看到项目已经启动成功
相关阅读:
https://juejin.cn/post/6873725957673320461
https://www.jianshu.com/p/a3609201b6cf
最新版本参照: Mobx6 https://blog.csdn.net/weixin_38245947/article/details/120338996
二 Mobx+React
2.1 安装Mobx
注意这里安装的版本, 最新版本已经是6了,
参照: https://blog.csdn.net/weixin_38245947/article/details/120338996
js
$ npm install mobx@5.15.4 mobx-react@6.2.2 -S2.2 工作流
2.3 创建Mobx工作流
@observable 可观测数据
将数据变为可观测数据, view才能看到变化
目录结构
js
+ store
+ CounterStore.js2.4 计数器案例
- 创建store对象，存储默认状态 store/CounterStore.js
jsx
// 1. 创建store对象 存储默认状态0
// 2. 将store对象放在一个全局的 组件可以够的到的地方
// 3. 让组件获取store对象中的状态 并将状态显示在组件中
import { observable, action, autorun } from 'mobx';
class CounterStore {
@action increment = () => {
this.count = this.count + 1;
}
@action decrement = () => {
this.count = this.count - 1;
}
}
const counter = new CounterStore();
export default counter;2.将store对象放在一个全局的组件可以得到的地方。 Provider
index.js中使用 Provider、counter
jsx
import React from 'react';
import ReactDOM from 'react-dom';
import { Provider } from 'mobx-react';
import App from './App';
import counter from './stores/counterStore';
ReactDOM.render(
<Provider counter={counter}><App /></Provider>,
document.getElementById('root')3.让组件获取store对象中的状态，并将状态显示在组件中
使用定义的counter //通过inject
App.js
jsx
import React, { Component } from "react";
import { inject, observer } from "mobx-react";
@inject("counter")
@observer
class App extends Component {
render() {
const { counter } = this.props;
return (
<div>
<button onClick={counter.increment}>+</button>
<span>{counter.count}</span>
<button onClick={counter.decrement}>-</button>
</div>
);
}
}
export default App;2.5. mobx异步
store/CounterStore.js
js
// 1。创建store对象，存储默认状态
// 2.将store对象放在一个全局的组件可以得到的地方。 Provider
// 3.让组件获取store对象中的状态，并将状态显示在组件中
import { observable, action, runInAction, flow } from "mobx"
import axios from 'axios'
class CounterStore {
// 可观测的数据
@observable count = 0
@observable users = []
// increment = () => {
// this.count = this.count + 1
// console.log(this.count)
// }
// decrement = () => {
// this.count = this.count - 1
// }
// 箭头头函数改成普通函数
@action.bound increment() {
this.count = this.count + 1
}
// 如果有异步操作，不能直接在这个函数中操作数据。处理方法如下：
// 方法1.runInAction
// @action.bound async getData () {
// let { data } = await axios.get('https://api.github.com/users');
// runInAction(() => {
// this.users = data || [{id: '1', login: '1'}]
// })
// }
// 方法2：flow
getData = flow(function * (){
let { data } = yield axios.get('https://api.github.com/users');
this.users = data || [{id: '1', login: '1'}]
}).bind(this)
}
const counter = new CounterStore()
export default counter2.6.mobx数据检测
数据检测：当某一个状态发生变化的时候我们想根据这个值得到另外一个值 计算值：可以根据现有的状态或其他计算值衍生出的值 mobx提供的方法： 1.computed 什么时候使用计算值？ 将复杂的业务逻辑从模板中进行抽离。 式例：
js
import {observable, action,computed} from 'mobx'
class BirdStore{
@observable count = 10
@observable price = 25
+ // 调用的时候可以不加括号，以属性的形式使用它。
@computed get totalPrice() {
return this.count * this.price
}禁止普通函数更改程序状态并引入action装饰器。 默认情况下所有的函数都可以更改程序的状态，但是我们觉得这样是不好的，如果程序状态出现了问题，我们不得不排查每一个更改应用程序状态的函数，这样开发成本就比较高的，所以我们要把这个默认行为禁止掉，也就是不希望所有的函数都可以更改应用程序的状态。我们强制规定只有@action函数可以更改应用程序的状态，降低了程序的开发成本。
js
// 1。创建store对象，存储默认状态
// 2.将store对象放在一个全局的组件可以得到的地方。 Provider
// 3.让组件获取store对象中的状态，并将状态显示在组件中
import { observable, action, runInAction, flow, configure } from "mobx"
import axios from 'axios'
// 通过配置强制程序使用action函数更改应用程序中的状态
configure({enforceActions: 'observed'})
class CounterStore {
// 可观测的数据
@observable count = 0
@observable users = []
+ @action increment = () => {
this.count = this.count + 1
console.log(this.count)
}
+ @action decrement = () => {
this.count = this.count - 1
}
const counter = new CounterStore()
export default counter数据检测（二）： autorun方法 当检测的状态发生变化的时候，你想根据状态产生‘效果’，请使用autorun autorun会在初始化的时候执行一次，会在每次状态发生变化时执行。
js
autorun(async () => {
let response = await uniqueUserName(this.username)
},{delay: 1500})三 .综合案例
案例： todo
js
{
"name": "todo",
"version": "0.1.0",
"private": true,
"dependencies": {
"@babel/plugin-proposal-decorators": "^7.8.3",
"@testing-library/jest-dom": "^4.2.4",
"@testing-library/react": "^9.5.0",
"@testing-library/user-event": "^7.2.1",
"customize-cra": "^0.9.1",
"mobx": "^5.15.4",
"mobx-react": "^6.2.2",
"react": "^16.13.1",
"react-app-rewired": "^2.1.6",
"react-dom": "^16.13.1",
"react-scripts": "3.4.1"
},
"scripts": {
"start": "react-app-rewired start",
"build": "react-app-rewired build",
"test": "react-app-rewired test",
"eject": "react-scripts eject"
},
"eslintConfig": {
"extends": "react-app"
},
"browserslist": {
"production": [
">0.2%",
"not dead",
"not op_mini all"
],
"development": [
"last 1 chrome version",
"last 1 firefox version",
"last 1 safari version"
]
}
}config-overrides.js
js
const { override, addDecoratorsLegacy } = require("customize-cra");
module.exports = override(addDecoratorsLegacy());index.js
js
import React from 'react';
import ReactDOM from 'react-dom';
import App from './components/App';
import todo from './stores/TodoStore';
import { Provider } from 'mobx-react';
import './index.css';
ReactDOM.render(
<Provider todo={todo}><App /></Provider>,
document.getElementById('root')
);index.css
css
html,
body {
margin: 0;
padding: 0;
}
button {
margin: 0;
padding: 0;
border: 0;
background: none;
font-size: 100%;
vertical-align: baseline;
font-family: inherit;
font-weight: inherit;
color: inherit;
-webkit-appearance: none;
appearance: none;
-webkit-font-smoothing: antialiased;
-moz-osx-font-smoothing: grayscale;
}
body {
font: 14px 'Helvetica Neue', Helvetica, Arial, sans-serif;
line-height: 1.4em;
background: #f5f5f5;
color: #4d4d4d;
min-width: 230px;
max-width: 550px;
margin: 0 auto;
-webkit-font-smoothing: antialiased;
-moz-osx-font-smoothing: grayscale;
font-weight: 300;
}
:focus {
outline: 0;
}
.hidden {
display: none;
}
.todoapp {
background: #fff;
margin: 130px 0 40px 0;
position: relative;
box-shadow: 0 2px 4px 0 rgba(0, 0, 0, 0.2),
0 25px 50px 0 rgba(0, 0, 0, 0.1);
}
.todoapp input::-webkit-input-placeholder {
font-style: italic;
font-weight: 300;
color: #e6e6e6;
}
.todoapp input::-moz-placeholder {
font-style: italic;
font-weight: 300;
color: #e6e6e6;
}
.todoapp input::input-placeholder {
font-style: italic;
font-weight: 300;
color: #e6e6e6;
}
.todoapp h1 {
position: absolute;
top: -155px;
width: 100%;
font-size: 100px;
font-weight: 100;
text-align: center;
color: rgba(175, 47, 47, 0.15);
-webkit-text-rendering: optimizeLegibility;
-moz-text-rendering: optimizeLegibility;
text-rendering: optimizeLegibility;
}
.new-todo,
.edit {
position: relative;
margin: 0;
width: 100%;
font-size: 24px;
font-family: inherit;
font-weight: inherit;
line-height: 1.4em;
border: 0;
color: inherit;
padding: 6px;
border: 1px solid #999;
box-shadow: inset 0 -1px 5px 0 rgba(0, 0, 0, 0.2);
box-sizing: border-box;
-webkit-font-smoothing: antialiased;
-moz-osx-font-smoothing: grayscale;
}
.new-todo {
padding: 16px 16px 16px 60px;
border: none;
background: rgba(0, 0, 0, 0.003);
box-shadow: inset 0 -2px 1px rgba(0,0,0,0.03);
}
.main {
position: relative;
z-index: 2;
border-top: 1px solid #e6e6e6;
}
label[for='toggle-all'] {
display: none;
}
.toggle-all {
position: absolute;
top: -55px;
left: -12px;
width: 60px;
height: 34px;
text-align: center;
border: none; /* Mobile Safari */
}
.toggle-all:before {
content: '❯';
font-size: 22px;
color: #e6e6e6;
padding: 10px 27px 10px 27px;
}
.toggle-all:checked:before {
color: #737373;
}
.todo-list {
margin: 0;
padding: 0;
list-style: none;
}
.todo-list li {
position: relative;
font-size: 24px;
border-bottom: 1px solid #ededed;
}
.todo-list li:last-child {
border-bottom: none;
}
.todo-list li.editing {
border-bottom: none;
padding: 0;
}
.todo-list li.editing .edit {
display: block;
width: 506px;
padding: 12px 16px;
margin: 0 0 0 43px;
}
.todo-list li.editing .view {
display: none;
}
.todo-list li .toggle {
text-align: center;
width: 40px;
/* auto, since non-WebKit browsers doesn't support input styling */
height: auto;
position: absolute;
top: 0;
bottom: 0;
margin: auto 0;
border: none; /* Mobile Safari */
-webkit-appearance: none;
appearance: none;
}
.todo-list li .toggle:after {
}
.todo-list li .toggle:checked:after {
}
.todo-list li label {
word-break: break-all;
padding: 15px 60px 15px 15px;
margin-left: 45px;
display: block;
line-height: 1.2;
transition: color 0.4s;
}
.todo-list li.completed label {
color: #d9d9d9;
text-decoration: line-through;
}
.todo-list li .destroy {
display: none;
position: absolute;
top: 0;
right: 10px;
bottom: 0;
width: 40px;
height: 40px;
margin: auto 0;
font-size: 30px;
color: #cc9a9a;
margin-bottom: 11px;
transition: color 0.2s ease-out;
}
.todo-list li .destroy:hover {
color: #af5b5e;
}
.todo-list li .destroy:after {
content: '×';
}
.todo-list li:hover .destroy {
display: block;
}
.todo-list li .edit {
display: none;
}
.todo-list li.editing:last-child {
margin-bottom: -1px;
}
.footer {
color: #777;
padding: 10px 15px;
height: 20px;
text-align: center;
border-top: 1px solid #e6e6e6;
}
.footer:before {
content: '';
position: absolute;
right: 0;
bottom: 0;
left: 0;
height: 50px;
overflow: hidden;
box-shadow: 0 1px 1px rgba(0, 0, 0, 0.2),
0 8px 0 -3px #f6f6f6,
0 9px 1px -3px rgba(0, 0, 0, 0.2),
0 16px 0 -6px #f6f6f6,
0 17px 2px -6px rgba(0, 0, 0, 0.2);
}
.todo-count {
float: left;
text-align: left;
}
.todo-count strong {
font-weight: 300;
}
.filters {
margin: 0;
padding: 0;
list-style: none;
position: absolute;
right: 0;
left: 0;
}
.filters li {
display: inline;
}
.filters li button {
color: inherit;
padding: 0 7px;
text-decoration: none;
border: 1px solid transparent;
border-radius: 3px;
}
.filters li button:hover {
border-color: rgba(175, 47, 47, 0.1);
}
.filters li button.selected {
border-color: rgba(175, 47, 47, 0.2);
}
.clear-completed,
html .clear-completed:active {
float: right;
position: relative;
line-height: 20px;
text-decoration: none;
cursor: pointer;
}
.clear-completed:hover {
text-decoration: underline;
}
.info {
margin: 65px auto 0;
color: #bfbfbf;
font-size: 10px;
text-shadow: 0 1px 0 rgba(255, 255, 255, 0.5);
text-align: center;
}
.info p {
line-height: 1;
}
.info a {
color: inherit;
text-decoration: none;
font-weight: 400;
}
.info a:hover {
text-decoration: underline;
}
/*
Hack to remove background from Mobile Safari.
Can't use it globally since it destroys checkboxes in Firefox
*/
@media screen and (-webkit-min-device-pixel-ratio:0) {
.toggle-all,
.todo-list li .toggle {
background: none;
}
.todo-list li .toggle {
height: 40px;
}
.toggle-all {
-webkit-transform: rotate(90deg);
transform: rotate(90deg);
-webkit-appearance: none;
appearance: none;
}
}
@media (max-width: 430px) {
.footer {
height: 50px;
}
.filters {
bottom: 10px;
}
}stores/TodoStore.js
js
import { observable, action, computed } from 'mobx';
class TodoStore {
// todo 列表
@observable todos = [];
// 筛选条件
@observable filter = 'All';
// 添加任务
@action.bound todoAdd (taskName) {
this.todos.push({
taskName,
isCompleted: false
})
}
// 删除任务
@action.bound todoDelete (index) {
this.todos.splice(index, 1);
}
// 更改任务的是否已完成状态
@action.bound changeCompleted (index, flag) {
this.todos[index].isCompleted = flag;
}
@computed get unfinishedTodoCount () {
return this.todos.filter(todo => todo.isCompleted === false).length;
}
// 更改筛选条件
@action.bound changeFilter(condition) {
this.filter = condition
}
// 监测筛选条件的变化 根据筛选条件对任务进行筛选
@computed get filterTodo () {
switch (this.filter) {
case 'All':
return this.todos;
case 'Active':
return this.todos.filter(todo => todo.isCompleted === false);
case 'Completed':
return this.todos.filter(todo => todo.isCompleted === true);
}
}
}
const todo = new TodoStore();
export default todo;components/App.js
js
import React, { Component } from 'react';
import AddTodo from './addTodo';
import TodoList from './todoList';
import TodoExtra from './todoExtra';
class App extends Component {
render() {
return <section className="todoapp">
<AddTodo />
<TodoList />
<TodoExtra />
</section>
}
}
export default App;components/addTodo.js
js
import React, { Component } from "react";
import { inject, observer } from "mobx-react";
@inject('todo')
@observer
class AddTodo extends Component {
// 添加任务
addTodo (event) {
const { todoAdd } = this.props.todo;
// 判断用户敲击的是否是回车键
if (event.key === 'Enter') {
// 获取用户在文本框中输入的内容
const taskName = event.target.value;
// 判断用户在文本框中是否输入了内容
if (taskName.trim().length === 0) {
// 阻止程序向下执行
return;
}
// 将任务添加到任务列表数组中
todoAdd (taskName);
// 清空文本框中的内容
event.target.value = '';
}
}
render() {
return (
<header className="header">
<h1>todos</h1>
<input onKeyUp={this.addTodo.bind(this)} className="new-todo" placeholder="What needs to be done?" />
</header>
);
}
}
export default AddTodo;components/todoList.js
js
import React, { Component } from "react";
import { inject, observer } from "mobx-react";
@inject("todo")
@observer
class TodoList extends Component {
render() {
const { todoDelete, changeCompleted, filterTodo } = this.props.todo;
return (
<section className="main">
<input className="toggle-all" type="checkbox" />
<ul className="todo-list">
{filterTodo.map((todo, index) => {
return (
<li className={todo.isCompleted ? 'completed': ''} key={todo.taskName}>
<div className="view">
<input onChange={event => changeCompleted(index, event.target.checked)} checked={todo.isCompleted} className="toggle" type="checkbox" />
<label>{todo.taskName}</label>
<button onClick={() => todoDelete(index)} className="destroy"></button>
</div>
<input className="edit" />
</li>
);
})}
</ul>
</section>
);
}
}
export default TodoList;components/todoExtra.js
js
import React, { Component } from "react";
import { inject, observer } from "mobx-react";
@inject("todo")
@observer
class TodoExtra extends Component {
render() {
const { unfinishedTodoCount, changeFilter, filter } = this.props.todo;
return (
<footer className="footer">
<span className="todo-count">
<strong>{unfinishedTodoCount}</strong> item left
</span>
<ul className="filters">
<li>
<button className={filter === 'All' ? 'selected': ''} onClick={() => changeFilter('All')}>All</button>
</li>
<li>
<button className={filter === 'Active' ? 'selected': ''} onClick={() => changeFilter('Active')}>Active</button>
</li>
<li>
<button className={filter === 'Completed' ? 'selected': ''} onClick={() => changeFilter('Completed')}>Completed</button>
</li>
</ul>
<button className="clear-completed">Clear completed</button>
</footer>
);
}
}
export default TodoExtra;
https://zhuanlan.zhihu.com/p/407390704
总结： \1. Mobx5 + Mobx-React6 主要是在子Store依赖Mobx中的这几个方法 obsevable, action, computed, autorun \2. @observeable 是用来修饰响应式变量的 \3. @action是用来修饰修改修改@aboserveable修饰的变量的 \4. @autorun是用来修饰自动运行方法的 \5. @computed是用来修饰修改@observeable修饰的响应式变量的，需要注意使用@computed修饰的方法前面必须加上get
// @computed 状态发生变化时候会自动执行
// 这样就<无需关注复杂业务逻辑>, 只要是能计算出来的值就可以使用
\6. 在根组件中使用mobx-react中的Provider组件将store注入所有组件 \7. 在组件使用的话可以使用构造器语法，回更方便使用mobx中的数据，但是装饰器语法的需要配置相应的babel插件 ["@babel/plugin-proposal-decorators", { "legacy": true }], ["@babel/plugin-proposal-class-properties"] 注意顺序不能反了，这样就是@inject(['good']) @observer 顺序也不反，数组语法也是因为可能会使用多个子store，如果没有配置装饰器语法的就是要类似于高阶组件的使用方法 @inject(['good']) @observer（组件）这样的语法来写
